Chapter 1
Available Spares
[A] IMPELLERS
S. No
Item Name with Details
Photographs
1.
G.M Impeller 12’’x14’’
O.D = 13.5 inch
Shaft dia. = 25 mm
Height = 6 inch
Weight = 12.5 Kg
Qty = 02 No.
2.
C.I Impeller
O.D = 10 inch
Shaft dia. = 25 mm
Height = 9.5 inch
Weight = 17 Kg
Qty = 01 No.
3.
Impeller Bronze
O.D = 15 inch
Shaft dia. = 50 mm
Height = 6 inch
Weight = 24.5 Kg
Qty = 02 No.
4.
Impeller Bronze
O.D = 16.5 inch
Shaft dia. = 60 mm
Height = 9.5 inch
Weight = 45.5 Kg
Qty = 01 No.
5.
Bronze Impeller (472 mm)
O.D = 17.5 inch
Shaft dia. = 50 mm
Height = 8.5 inch
Weight = 32 Kg
Qty = 02 No.
6.
Bronze Impeller
O.D = 307 mm
Shaft dia. = 25 mm
Height = 5 inch
Weight = 10.65 Kg
Qty = 01 No.
[B] WEAR RINGS
1.
Wear Ring 1
I.D = 210 mm
Wall thickness = 7 mm
Height = 15 mm
Qty = 05 No.
Wear Ring 1
I.D = 150 mm
Wall thickness = 5 mm
Height = 15 mm
Qty = 04 No.
[C] BEARINGS
1.
USSR 319
O.D = 200 mm
I.D = 95 mm
Width = 45 mm
Qty = 04 No.
2.
NJ 321
O.D = 225 mm
I.D = 105 mm
Width = 50 mm
Qty = 04 No.
3.
SKF 7322 BECBM
O.D = 240 mm
I.D = 110 mm
Width = 50 mm
Qty = 06 No.
4.
32324-M
O.D = 260 mm
I.D = 120 mm
Width = 55 mm
Qty = 03 No.
5.
SKF NU 322 ECJ
O.D = 240 mm
I.D = 110 mm
Width = 50 mm
Qty = 03 No.
[D] PUMP GLANDS
1
Split Gland
Size = 200 x 100 mm
I.D = 60 mm
Qty = 03 No.
2.
Split Gland
Size = 165 x 90 mm
I.D = 55 mm
Qty = 02 No.
3.
Bronze Split Gland
Size = 235 x 135 mm
I.D = 85 mm
Qty = 01 No.
4.
Pump Gland
Size = 130 x 100 mm
I.D = 50 mm
Qty = 24 No.
[E] BUSHS
1.
Bush
O.D = 85 mm
I.D = 75 mm
Length = 100 mm
Qty = 04 No.
2.
Bush (GM)
O.D = 75 mm
I.D = 60 mm
Length = 90 mm
Qty = 04 No.
3.
Bush (Bronze)
O.D = 115 mm
I.D = 90 mm
Length = 200 mm
Qty = 01 No.
(Octagonal inside)
[F] SHAFTS
1.
Impeller shaft
Length = 32 in
Dia = 50 mm
Qty = 04 No.
2.
Propeller shaft
Length = 26 in
Dia = 30 mm
Qty = 07 No.
3.
EN-8 Pump Shaft
Length = 46 in
Dia = 50 mm
Qty = 03 No.
4.
Pump/ Line Shafts of assorted sizes:
• Length = 48 in; Dia = 50 mm; Qty = 01 No.
• Length = 33 in; Dia = 50 mm; Qty = 03 No.
• Length = 56 in; Dia = 50 mm; Qty = 01 No.
• Length = 45 in; Dia = 55 mm; Qty = 01 No.
• Length = 54 in; Dia = 65 mm; Qty = 01 No.
• Length = 61 in; Dia = 60 mm; Qty = 01 No.
• Length = 64 in; Dia = 80 mm; Qty = 01 No.
