Chapter 1
TensorFlow/Keras Image Pipeline
Overview
A folder of image paths becomes model-ready only after metadata, decoding, resizing, batching, and visual validation are connected. The Data-to-Display Conveyor uses pandas for indexed metadata, tf.data for efficient input flow, and Keras preprocessing for consistent image tensors; use it whenever labels originate from a CSV or directory listing.
Quick Reference
Stage
API
Output
Metadata
pandas.read_csv()
DataFrame with paths and labels
Split
DataFrame.sample()
Training and validation rows
Decode
tf.io.read_file(), tf.image.decode_jpeg()
Image tensor
Resize
tf.image.resize()
Fixed-size tensor
Preprocess
keras.layers.Rescaling()
Floating-point values
Pipeline
tf.data.Dataset
Batched, prefetched data
Visual check
matplotlib.pyplot.imshow()
Image grid with labels
Parameters
Parameter
Type
Required
Description
csv_path
str
Yes
CSV containing filepath and label columns.
image_size
tuple[int, int]
No
Target height and width; default (224, 224).
batch_size
int
No
Images per batch; default 32.
validation_fraction
float
No
Fraction reserved for validation; default 0.2.
seed
int
No
Reproducible split and shuffle seed; default 42.
num_parallel_calls
int or tf.data.AUTOTUNE
No
Parallel mapping workers; default AUTOTUNE.
shuffle_buffer
int
No
Training shuffle buffer size; default 1000.
Code Example
import pandas as pd import tensorflow as tf import matplotlib.pyplot as plt from tensorflow import keras
CSV columns: filepath,label df = pd.read_csv("images.csv") df["label_id"] = df["label"].astype("category").cat.codes
train_df = df.sample(frac=0.8, random_state=42) valid_df = df.drop(train_df.index)
image_size = (224, 224) batch_size = 32 num_classes = df["label_id"].nunique()
def decode_image(path, label): image = tf.io.read_file(path) image = tf.image.decode_jpeg(image, channels=3) image = tf.image.resize(image, image_size) image = tf.cast(image, tf.float32) / 255.0 return image, label
def make_dataset(frame, training=False): paths = frame["filepath"].to_numpy() labels = frame["label_id"].to_numpy() ds = tf.data.Dataset.from_tensor_slices((paths, labels)) if training: ds = ds.shuffle(1000, seed=42, reshuffle_each_iteration=True) return (ds.map(decode_image, num_parallel_calls=tf.data.AUTOTUNE).batch(batch_size).prefetch(tf.data.AUTOTUNE))
train_ds = make_dataset(train_df, training=True) valid_ds = make_dataset(valid_df)
Keras preprocessing can be inserted before a model. preprocess = keras.Sequential([ keras.layers.RandomFlip("horizontal"), keras.layers.RandomRotation(0.05), ])
images, labels = next(iter(train_ds)) augmented = preprocess(images, training=True)
plt.figure(figsize=(8, 8)) for i in range(min(9, len(images))): plt.subplot(3, 3, i + 1) plt.imshow(augmented[i]) plt.title(f"class={labels[i].numpy()}") plt.axis("off") plt.tight_layout() plt.show() Response Format
The pipeline returns batches with this structure:
{ "images": "float32 tensor with shape [batch_size, 224, 224, 3], values in [0, 1]", "labels": "int32 tensor with shape [batch_size]", "example": { "image": "decoded RGB image resized to the configured dimensions", "label": "integer class ID derived from the pandas category mapping" } } Notes & Best Practices
• Validate paths before creating the dataset; missing files fail during iteration, not CSV loading.
• Use stratified splitting when classes are imbalanced; a random split can omit rare labels from validation.
• Match preprocessing to the model. Do not divide by 255 twice when using keras.layers.Rescaling(1./255).
• Inspect unaugmented and augmented batches. Incorrect color channels, distorted aspect ratios, and label mismatches are easiest to detect before training.
