Register Transfer And Microoperations

Parameters | Parameter | Type | Required | Description | |---|---|---|---| | stmt | string | Yes | A single RT-Lang statement: transfer, expression assignment, or guarded action | | Rdst | register identifier | Yes | Destination register name (e.g., R1, PC, IR, MAR, MDR) | | Rsrc | register identifier | Conditional | Source register name when doing Rdst ← Rsrc | | cond | boolean expression | Yes (for guarded statements) | Condition over flags and/or registers, e.g., Z=1, N=0, (IR[15:12] = 4) | | expr | expression string | Conditional | ALU expression on RHS: A + B, A AND B, SHIFT(A, k) | | k | integer | Conditional | Shift amount for shift microoperations, e.g., k=1 or k=IR[3:0] | | BUS | literal | Conditional | Symbolic bus name used only with bus-visible notation: (BUS) | | flags | set | Contextual | Z,N,C,V assumed available from prior ALU microoperations in the same control interval |

Code Example `rtlang; Priya: express a conditional register load sequence for a control step

; Assumptions:; - Flags (Z, N, C, V) are updated by the most recent ALU operation.; - (BUS) denotes the current bus value selected by the control unit.

; 1) Compute candidate result and update flags R3 ← R1 + R2; ALU add; Z/N/C/V reflect this operation

; 2) Conditional transfer based on Zero flag IF Z = 1 THEN R4 ← R3

; 3) Ordered bus read for an address register if result is non-negative IF N = 0 THEN MAR ← (BUS); bus must already be driven with the intended address source

; 4) End of microoperation sequence for this control step; (Statements separated by ';' execute in order) `

Response Format json { "rtlang": { "statements": [ { "type": "transfer|conditional|expression", "text": "string", "destination": "register | null", "source": "register | expression | bus | null", "condition": "boolean expression | null", "sequence_index": 0 } ], "bus_reads": [ { "destination": "register", "source": "(BUS)", "requires_bus_driver": true } ], "flags_used": ["Z", "N", "C", "V"] }, "validation": { "parsed_ok": true, "errors": [ { "code": "string", "message": "string", "location": { "sequence_index": 0, "span": [0, 0] } } ] } } Field meanings: - statements[]: ordered parse of each stmt in the microoperation sequence. - bus_reads[]: explicit tracking of (BUS) usage to prevent missing bus-driver selection. - validation.errors[]: syntax/semantic issues such as undefined registers or malformed IF.

Notes & Best Practices - Sequencing is explicit: use; to enforce order. Without it, a decoder may treat statements as parallel in the same control tick. - Guarded bus reads require a bus driver: (BUS) only yields a meaningful value if the control unit selects a source onto the bus in the same or preceding step. - Flag dependencies are temporal: cond tests flags produced by the most recent ALU microoperation; avoid mixing unrelated flag producers. - Prefer fully specified conditions: write Z=1 rather than relying on implicit truthiness, especially when conditions include multiple flags or bit slices like IR[15:12].

This syntax becomes the input format for the next chapter’s microoperation sequencing and control decoding rules, where these RT-Lang statements are mapped onto concrete register, bus, and ALU actions.

End of chapter one. 4 more chapters in the full book.
