A logic analyzer sees only what the ATmega328P outputs; the rest is inference. The Boot-to-Bit Trace Method pins that inference to concrete artifacts across the full toolchain: bootloader → flash → reset vector → timers/ADC registers → observable pins and serial bytes.

OverviewThis section documents how to bring up an Arduino Uno (ATmega328P) from the first compile through upload, then verify execution by tracing from bootloader behavior to register-level peripherals (timers and ADC). Use it when initial code “uploads” but nothing measurable happens on pins, UART, or ADC readings.

Quick ReferenceStage

What to verify

What you observe

Build

Correct target and compile flags

.hex size and symbol availability

Upload

Correct programmer/port

Bootloader handshake success

Reset/boot

Reset vector execution

UART/LED activity timing

Runtime

Timers configured as expected

PWM frequency/duty or toggle rate

Runtime

ADC configured and sampled

UART prints of analogRead()-equivalent values

Key endpointsATmega328P memory: Flash (program), SRAM (runtime), EEPROM (persistent).

Registers: Control/status for timers and ADC.

Timers: Deterministic timebase for PWM and periodic tasks.

ADC: Deterministic sampling for analog inputs.

ParametersParameter

Type

Required

Description

MCU

string

Yes

Select ATmega328P target for Arduino Uno builds

Clock

Hz (integer)

Yes

System clock used by timer/ADC configuration calculations

Bootloader

string

Yes

Uno bootloader must match upload protocol

BaudRate

integer

Yes

UART rate for serial trace verification

TimerID

enum

Yes

Select timer peripheral (e.g., Timer0/Timer1/Timer2)

PWM_Freq_Hz

float

No (default: derived)

Desired PWM frequency; used to compute prescaler/top

ADC_Channel

integer

Yes

ADC input channel index (0-7 on Uno)

ADC_Ref

enum

Yes

ADC reference selection (e.g., AVcc vs internal)

ADC_Prescaler

integer

No (default: 128)

ADC conversion clock divider; affects sample time

SampleCount

integer

Yes

Number of ADC samples to average/filter

TraceMode

enum

No (default: UART)

UART byte prints or pin toggles for timing visibility

Code Example// Boot-to-Bit Trace Method: verify boot -> timer -> ADC -> observable UART bytes.

// Target: Arduino Uno (ATmega328P)

#include <avr/io.h>

#include <util/delay.h>

static void initTimer1_CTC_1kHz() {

// Timer1 CTC: toggle output compare match (OC1A) at 1 kHz event rate.

// This config is deterministic and measurable on the scope/logic analyzer.

TCCR1A = 0; // Normal port operation; CTC set in TCCR1B

TCCR1B = 0;

// WGM12=1 => CTC mode with OCR1A as TOP

TCCR1B |= (1 << WGM12);

// Prescaler 64: adjust if you change Clock

TCCR1B |= (1 << CS11) | (1 << CS10);

// 16 MHz / 64 = 250 kHz timer clock. For 1 kHz: OCR1A = 250 - 1 = 249.

OCR1A = 249;

// Enable compare interrupt for precise periodic action

TIMSK1 |= (1 << OCIE1A);

}

static void initADC_AVcc_CH0() {

// Reference: AVcc, input: ADC0 (channel 0)

ADMUX = (1 << REFS0) | (0 << MUX0); // REFS0=AVcc; MUX=000 for ADC0

// Prescaler 128: typical for 125 kHz ADC clock at 16 MHz

ADCSRA = 0;

ADCSRA |= (1 << ADEN); // Enable ADC

ADCSRA |= (1 << ADPS2) | (1 << ADPS1) | (1 << ADPS0); // prescaler 128

// Optional: clear flags

ADCSRA |= (1 << ADIF);

}

static uint16_t readADC_OneShot() {

// Start single conversion

ADCSRA |= (1 << ADSC);

// Wait for conversion complete

while (!(ADCSRA & (1 << ADIF))) { / spin / }

// Clear flag by writing 1

ADCSRA |= (1 << ADIF);

// 10-bit result: ADCL first, then ADCH

uint8_t low = ADCL;

uint8_t high = ADCH;

return (uint16_t)high << 8 | low;

}

volatile uint16_t adcLast = 0;

ISR(TIMER1_COMPA_vect) {

adcLast = readADC_OneShot();

}

void setup() {

// UART trace: compile/upload correctness and boot completion verification.

Serial.begin(115200);

initTimer1_CTC_1kHz();

initADC_AVcc_CH0();

sei(); // enable interrupts

}

void loop() {

static uint16_t lastSent = 0;

// Emit when the ISR updates adcLast (1 kHz by timer config).

if (adcLast != lastSent) {

lastSent = adcLast;

Serial.print("ADC=");

Serial.println(adcLast);

}

}Response Format{

"stage": "string",

"status": "ok | error",

"observations": {

"uartBytes": "integer",

"ledOrPinToggleHz": "number",

"adcLast": "integer"

},

"registerSnapshot": {

"TCCR1A": "hex",

"TCCR

B": "hex",

"TCCR1B": "hex",

"OCR1A": "integer",

"TIMSK1": "hex",

"ADMUX": "hex",

"ADCSRA": "hex",

"ADCL": "hex",

"ADCH": "hex"

},

"notes": {

"timestampSource": "Timer1 compare match ISR",

"adcScaling": "raw10bit (0-1023)"

},

"errors": [

{

"code": "string",

"message": "string"

}

]

}Notes & Best PracticesRegister write ordering: For the ADC, read ADCL before ADCH to preserve a coherent 10-bit sample; the combined value is (ADCH << 8) | ADCL.

...
